3SE5122-0CB01

Description

Position switch

The SIRIUS 3SE5 position switches are designed for position sensing of machine parts and monitoring of protection equipment.

Technical details:

• Metal enclosure
• 56 mm wide
• Device connection 3x (M20x 1.5)
• 1 NO/1 NC quick action contacts
• Plain plunger, stainless steel
• Modular design permits a host of variants
• Wide variety of plug-in connectors and rollers
• LEDs indicate the current state of the device
• Quick-connect technology reduces connection time
• Operating points and mounting in accordance with EN 50047 and EN 50041
• Worldwide approval (IEC, UL)
• Meets highest safety requirements specified by PL e or SIL 3
• Integrated ASIsafe electronics requires low current input
• Various enclosure sizes available in plastic or metal
• Some versions optionally with LED status display and M12 plug
• 3SF1 series with direct connection to the AS-Interface bus system

Customer benefits:

• Time-efficient installation due to quick-connect technology
• High safety standards met by design
• Flexibility with a wide range of variants and connectors
• Visibility of device status through LED indicators
• Robust construction in metal or plastic
