3RA6120-2EB33

Description

Sirius Compact Load Feeder DOL Starter

The SIRIUS Compact load feeder DOL starter is designed for direct starting of standard three-phase motors up to 32 A, ensuring high operational reliability and space-saving design.

Technical details:

• Model: SIRIUS 3RA61
• Voltage: 690 V
• Control Voltage: 24 V AC/DC
• Frequency: 50…60 Hz
• Current: 8…32 A
• Degree of Protection: IP20
• Connection Main Circuit: Plug-in, without terminals
• Connection Auxiliary Circuit: Spring-type terminal
• Approval: IEC and UL/CSA

Customer benefits:

• Combines the functions of circuit breaker, contactor, and electronic overload relay for efficiency.
• Extremely high operational reliability.
• Low number of variants simplifies logistics.
• Compact design saves space in the control cabinet.
• Easy replacement due to removable terminals.
• Available as direct-on-line or reversing starters with various setting ranges.
• Designed for AC/DC operation with screw or spring-loaded terminals or without terminals.
• Communication link via AS-interface and availability of accessories like 3RA68 infeed system and auxiliary contacts.
• Part of the simple, efficient, and always up-to-date SIRIUS modular system.
